PTO Rotary Tiller for Compact Tractors
This PTO rotary tiller is designed for connection to compact tractors, providing efficient soil preparation and cultivation. It features a chain-driven transmission and a graphite casting iron gearbox for enhanced durability.
Technical Specifications
Product Overview
Versatile PTO Rotary Tiller
This PTO-driven rotary tiller is engineered for efficient soil preparation and cultivation on small to medium-sized farms. Designed for 15-35hp compact tractors, it features a robust graphite casting iron gearbox and a flexible chain-driven transmission for reliable performance. With adjustable tilling height and integrated side protection plates, it ensures a fine tilth while preventing soil displacement during operation.
Technical Performance
Performance Highlights
540 rpm
PTO Input Speed
15 hp
Min Tractor Power
35 hp
Max Tractor Power
- Transmission System
- Chain driven
- Gearbox Material
- Graphite casting iron
Design & Safety
Adjustable Components
- Hand adjustable chain device
- Adjustable tilling height
- Deformation-resistant suspension plate
- Linkage System
- Three point linkage
- Safety & Protection
- Protection BarSide Protection PlatesRear Deflection Shield
Model Specifications
Model Comparison
| Model | Working Width (cm) | Weight (kg) | Blades | Dimensions (mm) |
|---|---|---|---|---|
| RT-85 | 85 | 110 | 16 | 950*550*560 |
| RT-95 | 95 | 115 | 16 | 1050*550*560 |
| RT-105 | 105 | 125 | 20 | 1150*550*560 |
| RT-115 | 115 | 135 | 24 | 1250*550*560 |
| RT-125 | 125 | 145 | 28 | 1350*550*560 |
| RT-135 | 135 | 155 | 32 | 1450*550*560 |
