Product Overview
High-Performance Geocell Production Line
This production line is engineered for the automated manufacturing of high-tensile thermoplastic geocells using PP or PE materials. Through a sophisticated process including extrusion and ultrasonic welding, it creates three-dimensional alveolate structures capable of reinforcing roadbeds, controlling erosion, and supporting earth-retention walls. Designed for efficiency and consistent quality, this system helps manufacturers produce durable geosynthetics that effectively manage load distribution and soil stability in demanding civil engineering projects.
Technical Specifications
Performance Parameters
| Parameter | Model JG-TGGC90 | Model JG-TGGC120 |
|---|---|---|
| Raw Material | PP/PE | PP/PE |
| Sheet Thickness (mm) | 1.1, 1.2, 1.5, 1.8 | 1.1, 1.2, 1.5, 1.8 |
| Geocell Height (mm) | 50, 75, 100, 150, 200 | 50, 75, 100, 150, 200, 300 |
| Welding Distance (mm) | 340-800 | 340-800 |
| Unfolding Area (m²) | 4 × 5 | 4 × 5 |
| Dimensions (L×W×H) (m) | 28 × 5 × 3 | 30 × 8 × 3 |
Certifications & Standards
- Quality Compliance
- ISO9001CETUV
