Petrochemical Conversion Furnace
This conversion furnace is designed for petrochemical engineering applications within petroleum refineries. It is constructed as a cylindrical pressure vessel to withstand high temperatures and pressures.
Technical Specifications
Overview
Industrial Conversion Furnace
This high-capacity petrochemical conversion furnace is engineered for demanding refinery environments, facilitating critical chemical reactions and heat exchange processes. Constructed with premium SA387Gr.11CL2+ steel and featuring 321 surfacing, the unit is built to withstand rigorous industrial conditions. With a robust design capable of operating at pressures up to 7.15 MPa and temperatures of 480°C, this vessel provides reliable performance for large-scale chemical engineering operations.
Technical Specifications
- Design Pressure
- 7.15 MPa
- Set Temperature
- 480 °C
- Total Weight
- 112.3 T
Construction & Materials
- Material Grade
- SA387Gr.11CL2+
- Surfacing
- 321
Dimensions
- Dimensions (Φ x L x T)
- Φ2590 x 12770 x (105+5) mm
Performance Metrics
Key Operational Metrics
7.15 MPa
Design Pressure
480 °C
Set Temperature
112.3 T
Total Weight
