Orchard Pesticide Spraying Robot
This robot is designed for precise and efficient pesticide spraying in orchards. It features a 320L loading volume, a spraying radius of 6-7 meters, and can operate for 6 hours on a single charge.
Technical Specifications
Overview
Intelligent Orchard Spraying Solution
The intelligent orchard spraying robot is an advanced agricultural platform designed for autonomous inspection and precision pesticide application. Featuring a robust 4WD electric chassis with high ground clearance, it navigates complex terrains including hills and mountainous regions with ease. By integrating high-precision GPS/RTK navigation and intelligent sensors, it minimizes manual labor and human exposure to harmful chemicals while maximizing operational efficiency.
Technical Specifications
Supported Environments
- Orchards
- Vegetable fields
- Hills
- Mountainous regions
- Greenhouses
- Tea gardens
- Dimensions (L*W*H)
- 2400×1800×2200 mm
- Weight
- 900 kg
- Loading Volume
- 320 L
- Applicable Crops
- Peach treesApple treesOrange trees
- Navigation Mode
- Fully automatic (GPS+RTK+ high-precision map)
Performance Metrics
Key Performance Indicators
10 mu/h
Operation Efficiency
6 hours
Battery Mileage
7 m
Spraying Radius
Features
Intelligent Functions
- Pedestrian recognition
- Intelligent obstacle avoidance
- Fruit tree recognition
- Targeted spraying
