Technical Specifications
Overview
AC30 Modular Socket Receptacles
The AC30 series modular sockets are designed for high-performance power distribution in residential, commercial, and industrial settings including hotels, airports, and docks. These units offer a versatile modular design that integrates seamlessly with circuit breakers and lighting distribution boxes. Engineered for safety and reliability, they are fully compliant with international and domestic quality standards.
Standards
- Certified Standards
- GB2099IEC60884-1
Technical Specifications
Technical Overview
240 V
Rated Voltage (Single Phase)
415 V
Rated Voltage (Multi-jack)
25 A
Max Rated Current
Model Configurations
| Model Type | Current (A) | Voltage (V) | Max Conductor Area |
|---|---|---|---|
| Single-phase two-Jack | 10,16 | 240 | <=10 |
| Single-phase three-Jack | 10,16,25 | 240 | <=16 |
| Single-phase four-Jack | 16,25 | 415 | <=16 |
Installation
Mounting & Physical
- Modular design for quick integration
- Compatible with DIN rail mounting systems
- Compatible with YFN and DZ47 series circuit breakers
