Laser Applique Cutting Machine
This machine utilizes laser technology to cut applique logos. It provides precise and efficient cutting for various materials.
* Using category placeholder image
Technical Specifications
Overview
Precision Laser Cutting for Labels and Appliques
This series of automatic recognition laser cutting machines is engineered for high-precision processing of diverse materials including woven, leather, vinyl, and multi-ply labels. Featuring advanced CCD camera technology, these machines enable accurate whole-format cutting without material loss, significantly enhancing production efficiency. With options for kiss-cutting, vacuum conveyor tables, and double-head configurations, this equipment is ideal for the textile, toy, and embroidery industries.
Applications
- Supported Materials & Applications
- Woven LabelsLeather LabelsAdhesive LabelsVinyl LabelsDomed LabelsEmbroidery PatchesTextile/FabricRibbons
Technical Specifications
Model Specifications
| Model | Working Area | Laser Type | Power Options |
|---|---|---|---|
| ZDJG-9050/12060 | 900x500mm / 1200x600mm | DC Glass CO2 | 65W/80W/100W |
| ZDJG-10050 | 1000x500mm | DC Glass CO2 | 80W/150W RF |
| ZDJG-15090LD | 1500x900mm | DC Glass CO2 | 80W/150W RF |
| ZDJGHY-15090LDII | 1500x900mm | DC Glass CO2 | 80Wx2 |
Performance
- Working Speed
- 36000 mm/min
- Motion System
- Step motor with online control system
- Power Supply
- AC220V ± 5% / 50Hz
Key Features
Advanced Capabilities
- Professional CCD Camera for accurate whole-format recognition
- Kiss-cutting capability for multi-ply labels
- Vacuum conveyor working table for continuous batch cutting
- Auto-feeding system for high-volume production
- Double laser head configuration for simultaneous label and fabric cutting
