IP68 Waterproof Cable Gland
These IP68 waterproof cable glands are designed for use on enclosure boxes, lamps, and other applications where a waterproof seal is required. The glands are constructed from UL-approved nylon and provide excellent strain relief.
Technical Specifications
Product Overview
Professional Grade IP68 Cable Glands
These high-quality waterproof cable glands are engineered for reliable cable entry in enclosure boxes, lighting fixtures, and industrial equipment. Featuring a durable nylon PA66 construction and EPDM rubber seals, they provide superior protection against environmental factors. The design includes a unique 'click' sound mechanism upon tightening, ensuring a secure, vibration-resistant hold with a wide clamping range.
Technical Specifications
Protection Rating
IP68
Operating Temperature Range
-40 °C
Min Temp
100 °C
Max Temp
- Construction Materials
- Nylon PA66EPDM Rubber
- Flammability Rating
- UL 94V-2 (UL 94V-0 available upon request)
Compatibility & Options
Available Thread Types
- PG
- Metric
- G
- NPT
Chemical Resistance
- Salt water
- Weak acid
- Alcohol
- Oil
- Grease
- Common solvents
- Standard Colors
- BlackGreyWhiteRed
