PG Cable Gland for Cable Entry
PG cable glands provide strain relief and protection for cables entering enclosures. They are made of durable materials and available in various sizes to accommodate different cable diameters.
Technical Specifications
Product Overview
Reliable Cable Entry Solution
These PG cable glands provide a robust and waterproof solution for secure cable entry in industrial and commercial environments. Designed with high-toughness claws, thick seal rings, and dual card buckles, they ensure excellent strain relief and protection against environmental factors like moisture and dust. They are engineered for durability, offering high sealing integrity and corrosion resistance for a wide range of cable diameters.
Technical Specifications
Key Performance Features
WaterproofCorrosion ResistantHigh ToughnessStrain Relief
- Available Models
- PG7PG9PG11PG13.5PG16PG21PG29PG36PG42PG48PG63
- Supported Cable Diameter Range
- 50 mm
Size Chart
Dimensions and Cable Range
| Model | Cable Range (mm) |
|---|---|
| PG7 | 3-6.5 |
| PG9 | 4-8 |
| PG11 | 5-10 |
| PG13.5 | 6-12 |
| PG16 | 10-14 |
| PG21 | 13-18 |
| PG29 | 18-25 |
| PG36 | 20-32 |
| PG42 | 32-38 |
| PG48 | 37-44 |
| PG63 | 42-50 |
