High Voltage Fused Cutout
This high-voltage fused cutout provides overcurrent protection in electrical distribution systems. It is suitable for outdoor applications and harsh environments, safeguarding against short circuits and overloads.
Technical Specifications
Product Overview
High Voltage Protection Solution
This outdoor high-voltage fused cutout serves as a critical protection appliance for electrical distribution networks. Designed for installation on the high-voltage side of distribution transformers or branch lines, it provides essential short-circuit and overload protection. The unit features a robust insulating bracket and a specialized fuse tube construction, ensuring reliable performance in harsh outdoor environments.
Technical Specifications
Construction Materials
- Insulating bracket
- Inner arc suppression tube
- Phenolic paper or epoxy glass cloth outer tube
- Elastic auxiliary contact
- Arc-extinguishing cover
Available Configurations
| Type | Key Feature |
|---|---|
| Standard Fuse Cut-out | Basic protection appliance |
| Load Fuse Cut-out | Includes auxiliary contact and arc-extinguishing cover |
- Protection Functions
- Short-circuit ProtectionOverload ProtectionLoad Current Switching
Application & Environment
Environment
OutdoorHigh-voltage DistributionHarsh Weather Resistant
Typical Applications
- Distribution transformers
- Branch distribution lines
- Overhead power lines
- Substations
