High Voltage Electrical Insulators
High voltage insulators provide insulation and support for high-voltage conductors in electrical systems. They are available in various sizes and configurations to meet specific application requirements in power transmission and distribution.
Technical Specifications
Product Overview
High Voltage Electrical Insulators
These high-voltage insulators are essential components designed for robust performance in power transmission and distribution networks. They provide critical insulation and mechanical support for high-voltage conductors, ensuring system reliability and safety. Engineered to withstand demanding electrical environments, these units are available in multiple configurations to meet diverse application requirements.
Technical Dimensions
Dimensional Data (mm)
| Parameter | Type 1 | Type 2 | Type 3 | Type 4 |
|---|---|---|---|---|
| A | 110 | 127 | 152 | 178 |
| B | 59 | 68 | 83 | 95 |
| C | 12 | 12 | 15 | 15 |
| D | 14.5 | 14.5 | 18 | 18 |
| E | 21 | 21 | 25 | 25 |
| F | 8 | 8 | 10 | 10 |
| G | 1.5 | 1.5 | 2 | 2 |
| H | 18.7 | 18.7 | 23.5 | 23.5 |
| I | 5.5 | 5.5 | 6 | 6 |
Performance Metrics
Mechanical Strength
40 KN
Min Strength (Type 1)
70 KN
Min Strength (Type 2/3)
100 KN
Min Strength (Type 4)
Weight
- 0.5 Kg
- 0.6 Kg
- 0.9 Kg
- 1.1 Kg
Electrical Characteristics
Electrical Performance
| Specification | Type 1 | Type 2 | Type 3 | Type 4 |
|---|---|---|---|---|
| Min Flashover Dry (KV) | 72 | 86 | 102 | 120 |
| Min Flashover Wet (KV) | 36 | 43 | 51 | 60 |
| Power Freq Withstand (KV) | 35 | 42 | 50 | 60 |
| Cantilever Strength (KN.M) | 1.08 | 1.1 | 1.8 | 2.5 |
