High-Strength Industrial Grinding Mill
This high-strength mill efficiently grinds materials like barite, limestone, and slag. It is used for fine powder processing in mining, metallurgy, chemical, and building material industries, with adjustable output sizes.
Technical Specifications
Overview
High-Strength Industrial Grinding Mill
This high-strength grinding mill is engineered for the efficient processing of non-flammable materials such as barite, limestone, slag, and ceramics. With a robust design capable of handling materials with Mohs hardness up to 9.3, it is ideal for mining, metallurgy, and chemical industries. The system offers adjustable output fineness, capable of reaching up to 1000 mesh, while maintaining high output efficiency and strict environmental compliance for dust emissions.
Application & Suitability
- Suitable Materials
- BariteLimestoneCeramicSlag
- Max Mohs Hardness
- 9.3
- Max Material Humidity
- 6 %
Technical Specifications
Model Specifications
| Model | Feeding Size (mm) | Output Range (t) | Ring Diameter (mm) |
|---|---|---|---|
| High-strength97 | ≤25 | 4-52 | 1,050 |
| High-strength93 | ≤25 | 3.5-40 | 1,006 |
| High-strength91 | ≤25 | 3-36 | 973 |
| High-strength87 | ≤25 | 2.8-33 | 907.5 |
| High-strength76 | ≤20 | 1.5-25 | 850 |
| High-strength66 | ≤15 | 1-20 | 725 |
| High-strength62 | ≤15 | 0.6-9 | 525 |
Key Features
Performance Highlights
20 %
Output Improvement
1,200 kg
Max Grinder Roll Pressure
1,000 mesh
Max Fineness
System Components
- Jaw Crusher
- Bucket Elevator
- Hopper
- Powder Collector
- Classifier
- Dust-Catcher
- Air-Blower
- High-pressure Mill
- Reducer
- Vibrating Feeder
