Glovebox with Gas and Solvent Purification
This glovebox system provides a controlled, inert atmosphere for sensitive research and manufacturing. It features a gas purification system to remove contaminants and a solvent purification system for organic solvents.
Technical Specifications
Product Overview
High-Performance Controlled Atmosphere System
This glovebox system is designed to provide a highly controlled, inert atmosphere essential for sensitive research and industrial manufacturing processes. Constructed from durable stainless steel, the unit features an integrated gas and solvent purification system to effectively remove oxygen and moisture, ensuring a stable environment. With advanced leakage protection and customizable dimensions, it offers a reliable solution for handling sensitive materials.
Glovebox Specifications
Available Dimensions (W x D x H)
- 1200mm x 780mm x 920mm
- 1450mm x 780mm x 920mm
- 1950mm x 780mm x 920mm
Weight
400 kg
Minimum Weight
550 kg
Maximum Weight
- Material Construction
- Stainless steel 1.4301 (US Type 304)
- Leak Rate
- <0.05 vol%h (acc. ISO 10648-2)
Technical Features
Vacuum Inserts
High VacuumKF 40
- Power Supply
- 220V (24V optional)
- Circulation System
- Air inlet and outlet equipped with HEPA filters
Antechamber Specifications
- Antechamber Dimensions
- 390mm diameter x 600mm length
- Antechamber Leak Rate
- <10^-5 mbar l/s (Class 1)
- Key Features
- Cylindrical designStainless steel sliding trayVertical gas piston doorsManual vacuum operation
