LPG Mounded Storage Tank
This LPG mounded tank is designed to safely store liquefied petroleum gas. It is constructed with materials SA-516 and SA-537 CL1 and adheres to ASME BPVC VIII-1/VIII-2 design codes.
Technical Specifications
Overview
LPG Mounded Storage Tank
These high-capacity LPG mounded storage tanks are engineered for the safe and efficient containment of liquefied petroleum gas in demanding petrochemical environments. The system supports flexible design configurations, including large-scale units without saddles and medium-to-small units with saddles, ensuring versatility for various site requirements. Built to rigorous international standards, these tanks prioritize safety, environmental protection, and long-term operational reliability.
Technical Specifications
Vessel Capacity Range
5 m3
Minimum Capacity
5,000 m3
Maximum Capacity
- Design Code
- ASME BPVC VIII-1/VIII-2
- Vessel Materials
- SA-516SA-537 CL1
- Filling Rate
- 0.85
Configuration Data
Tank Specifications by Volume
| Volume | Material | Empty Weight |
|---|---|---|
| 1000m3 | SA-537 CL.1(Normalized) | 172,610 KG |
| 2070m3 | SA-537 CL.1(Normalized) | 330,000 KG |
| 3500m3 | SA-537 CL1+S5 | 629,300 KG |
