Flex-Wing Rotary Mower
This flex-wing rotary mower is designed for compact and utility tractors. It features an increased side frame depth that enhances cut material capacity.
Technical Specifications
Product Overview
Professional Grade Flex-Wing Rotary Mower
The 9G series mower sets a high standard for flex-wing cutters, specifically designed for compact and utility tractors. It features the deepest deck in the industry to increase material capacity and improve cutting performance in challenging environments. This scientific design is ideal for cleaning brush, slashing grassland, and improving uneven ranch land with ease of operation and maintenance.
Key Performance Metrics
Performance Highlights
1,500 mm
Max Cutting Width
300 mm
Max Cutting Height
30 HP
Max Matched Power
Technical Specifications
Model Comparison
| Model | Width (mm) | Length (mm) | Height (mm) | Cutting Width (mm) | Weight (kg) | Power (HP) |
|---|---|---|---|---|---|---|
| 9G-1.0 | 1,200 | 1,400 | 800 | 1,000 | 260 | 18-30 |
| 9G-1.5 | 1,700 | 1,900 | 900 | 1,500 | 350 | 25-30 |
Design & Construction
Construction Features
- Heavy-duty steel frame with red protective finish
- Galvanized deck for superior corrosion resistance
- Deep deck design for increased material capacity
- Integrated safety chain curtains to prevent debris scattering
- Adjustable cutting height for versatile terrain management
Safety Equipment
Chain GuardsProtective HousingProjectile Hazard Shielding
Operation & Compatibility
- Linkage System
- 3-point mounted
- Power Transmission
- PTO ShaftGearbox DrivenHydraulic System Support
