Fire Suppression Water Pump
This fire pump is designed for high-performance fire suppression systems. It ensures a consistent water supply for firefighting operations with its durable construction and powerful motor.
Technical Specifications
Overview
High-Performance Fire Suppression Pump
This vertical inline fire suppression water pump is engineered for high efficiency and reliable operation in industrial, commercial, and municipal fire protection systems. Utilizing CFD computational fluid dynamics for optimized flow path design, it ensures superior hydraulic performance and energy savings. The robust construction includes a stainless steel shaft sleeve to prevent corrosion, simplifying maintenance and extending the operational lifespan of the unit.
Performance Metrics
Flow Range
5 L/s
Minimum Flow
100 L/s
Maximum Flow
Pressure Range
0.31 MPa
Min Pressure
2 MPa
Max Pressure
Technical Specifications
- Inlet/Outlet Diameter
- 25mm - 300mm
- Max Allowable Inlet Pressure
- 0.4 MPa
- Flange Pressure Class
- 1.6 MPa
- Motor Levels
- Level 2Level 4
- Max Medium Temperature
- 80 °C
Design Features
Key Design Features
- Vertical pipe structure for easy installation
- Direct motor-to-pump connection for stability
- Stainless steel shaft sleeve for corrosion resistance
- Rubber corrugated pipe mechanical seal
- CFD-optimized hydraulic profile
