Epoxy Coated Perforated Stainless Steel Strap Band
This perforated strap band is constructed from 304 or 316 stainless steel with an epoxy coating. It features strong tensile strength and is resistant to corrosion.
Technical Specifications
Overview
Professional Grade Stainless Steel Strapping
This epoxy-coated perforated stainless steel strap band is designed for demanding industrial applications requiring superior tensile strength and corrosion resistance. Featuring a reliable ball-lock self-locking mechanism, it offers quick and secure installation for both indoor and outdoor environments. The durable epoxy coating provides enhanced protection against chemicals, abrasion, and harsh weather conditions, ensuring long-lasting performance in critical bundling tasks.
Technical Specifications
Operating Temperature Range
-60 °C
Minimum
85 °C
Maximum
Dimensional Specs
- Available Widths: 4.6mm, 7.9mm, 10mm
- Thickness: 0.4mm
- Customizable length
- Material
- Stainless Steel 304Stainless Steel 316Epoxy Coated
Performance Data
Binding Capacity Table
| Model | Length (mm) | Max Diameter (mm) |
|---|---|---|
| TSRE-4.6 | 150 | 37 |
| TSRE-4.6 | 200 | 50 |
| TSRE-4.6 | 250 | 63 |
| TSRE-7.9 | 300 | 76 |
| TSRE-7.9 | 350 | 89 |
| TSRE-7.9 | 400 | 102 |
| TSRE-10 | 450 | 115 |
| TSRE-10 | 500 | 128 |
| TSRE-12 | 550 | 141 |
| TSRE-12 | 600 | 167 |
| TSRE-12 | 700 | 180 |
| TSRE-15 | 800 | 191 |
| TSRE-15 | 900 | 200 |
| TSRE-15 | 1,000 | 206 |
Features
Key Characteristics
Acid ResistanceCorrosion ResistanceHigh Tensile StrengthQuick InstallationSelf-Locking Ball Mechanism
