Electronic Variable Speed Wood Lathe with Delta Inverter
This electronic variable speed wood lathe has a 22x42 inch capacity and is powered by a 2200W motor. It features a Taiwan Delta inverter for precise speed control.
Technical Specifications
Overview
Professional Wood Turning Performance
This electronic variable speed wood lathe is engineered for stability and precision, featuring an all-cast iron construction that ensures vibration-free operation during heavy-duty turning. Equipped with a powerful 2200W motor and an advanced inverter system, it offers two belt ratios for high torque when working with large diameters. Designed with a digital speed display and a quick belt change headstock, this machine provides the control and efficiency required for professional woodworking projects.
Technical Specifications
Motor Power
2,200 W
Input Power
1,500 W
Output Power
Spindle Speed Ranges
| Ratio | Speed Range |
|---|---|
| Low (L) | 0-1200 RPM |
| High (H) | 0-3200 RPM |
- Swing Over Bed
- 22 inch
- Distance Between Centers
- 42 inch
Machine Configuration
Included Accessories
- 6-inch Face plate
- 14-inch Tool rest
- Headstock/Tailstock Taper
- MT2
- Drive Spindle Thread
- M33X3.5
Logistics
Weight
225 kg
Net Weight
300 kg
Gross Weight
- Packing Size
- 1750 x 610 x 620 mm
