Electrical Insulation Rigid Laminate
These rigid laminates are designed for electrical insulation applications. They offer excellent mechanical strength, electrical properties, and thermal resistance, making them suitable for demanding environments.
Technical Specifications
Product Overview
High-Performance Electrical Insulation
These rigid laminates are engineered for superior performance in demanding electrical and electronic environments. Manufactured by heat-pressing thermosetting resin-impregnated fabrics such as glass fiber, cotton, and basalt cloth, they provide exceptional mechanical strength and dielectric properties. Designed for reliability in power transmission and distribution, these materials offer the thermal stability and structural integrity required for critical insulation applications.
Material Composition
Available Material Grades
- G10/EPGC201
- G11/EPGC203
- FR4/EPGC202
- FR5/EPGC204
- GPO3/UPGM203
- Reinforcement Fabrics
- Glass fiber clothCotton clothBasalt fiber cloth
Application Scope
Suitable Industries
Electric Power TransmissionPower DistributionInsulation DevicesElectronics Manufacturing
