Technical Specifications
Product Overview
High-Performance Deep Cycle Power
Designed specifically for long-life deep cycle applications, this battery series utilizes advanced patent technologies to ensure exceptional durability. It is engineered to withstand 500-600 cycles at 100% depth of discharge, making it an ideal energy solution for electric bicycles, tricycles, golf carts, and other electric vehicle platforms. With a proven track record in demanding motive power environments, this battery provides consistent, reliable performance for high-frequency usage.
Technical Specifications
Charging Parameters
| Parameter | Value |
|---|---|
| Cycle Use Voltage | 14.4-15.0V |
| Float Use Voltage | 13.5-13.8V |
| Initial Current | < 5.1A |
- Voltage
- 12 V
- Capacity
- 17 Ah
- Cycle Life (100% DOD)
- 500-600 cycles
Applications & Compliance
Certifications
CE
- Suitable Applications
- Electric BicyclesElectric TricyclesGolf CartsEV/HEVMotive Power
Key Metrics
Performance Highlights
600 cycles
Max Cycle Life
17 Ah
Capacity
12 V
Nominal Voltage
