Continuous Slot Wire-Wrapped Well Screens
These wire-wrapped screens are constructed with a V-shaped wire around longitudinal support rods, creating continuous slot openings. This design allows water or oil to enter the well freely while keeping sand and gravel out.
Technical Specifications
Product Overview
Continuous Slot Well Screens
These rod-based wire-wrapped screens utilize a precision-engineered V-shaped profile wire helically wound around an internal support structure. Each intersection point is fusion-welded to create a continuous, clog-resistant slot opening. This design maximizes fluid intake while providing superior strength and preventing sand and gravel ingress in demanding well environments.
Technical Specifications
- Slot Size
- 0.1 - 3 mm
- Open Area
- 60 %
- Diameter Range
- 25 - 1500 mm
- Max Length
- 6 meters
Material Construction
- Material Options
- Low Carbon SteelGalvanized SteelStainless Steel 304Stainless Steel 316L
- Surface Treatment
- Anticorrosion coating available for low carbon steel
Key Features
Performance Advantages
- High structural strength
- Continuous slot geometry
- Clog-resistant design
- High flow capacity
- Effective sand control
