Continuous Slot Wire Wrapped Water Well Screen
Continuous slot wire wrapped screens filter sand and gravel from water wells. The wire-wrapped design maximizes water flow and prevents clogging.
Technical Specifications
Overview
High-Efficiency Continuous Slot Water Well Screens
These continuous slot wire-wrapped screens are engineered for high-performance water, oil, and gas well applications. Featuring a V-shaped profile wire wrapped around longitudinal support rods, the design maximizes open area to ensure optimal fluid intake while effectively filtering out sand and gravel. The robust, precision-welded construction provides exceptional durability, heat resistance, and anti-corrosive properties for a long operational service life.
Key Performance Metrics
Featured Specifications
6 m
Maximum Length
800 mm
Maximum Diameter
0.1 mm
Minimum Slot Size
Technical Dimensions
Wire and Rod Specifications
| Component | Width (mm) | Height (mm) |
|---|---|---|
| Profile Wire | 1.50, 1.80, 2.30, 3.00, 3.30, 3.70 | 2.20, 2.50, 2.70, 3.60, 4.30, 4.70, 5.60, 6.30 |
| Support Rods | 2.30, 3.00, 3.30, 3.70 | 2.70, 3.60, 4.70, 5.60, 6.30 |
- Round Support Rod Diameter
- 2.50mm to 6.0mm
Material & Construction
End Connection Types
- Plain beveled ends for butt welding
- Threaded connections
- Available Materials
- Low Carbon SteelGalvanized Steel (LCG)Stainless Steel 304Stainless Steel 316
Operational Benefits
Product Features
- Non-clogging V-shaped profile wire
- Large open area for low entrance velocity
- Reduced pump abrasion and energy consumption
- Easy backwashing capability
- High mechanical strength and collapse resistance
Applications
Water WellsOil WellsGas WellsEnvironmental RemediationMedium Filtering
