Cone Ball Mill Grinder for Material Processing
The Cone Ball Mill Grinder is a key grinding machine used to process crushed materials. It is widely applicable in powder-making production lines, including cement, silicate, and fertilizer.
Technical Specifications
Product Overview
Energy Saving Cone Ball Mill Grinder
The Energy Saving Cone Ball Mill Grinder is a high-efficiency grinding machine designed for processing crushed materials across various industries, including cement, mining, and new building materials. It features a robust horizontal cylinder design that utilizes centrifugal force and steel grinding media to pulverize materials effectively. This versatile unit supports both dry and wet grinding processes and is engineered for optimal energy savings during continuous operation.
Technical Specifications
Discharge Types
- Grate type
- Overfall type
- Grinding Capabilities
- Dry GrindingWet Grinding
Design & Operation
How it Works
The machine operates as a horizontal cylinder rotating device driven by gears. Materials enter the first silo via a feeding quill shaft, where they are crushed by steel balls lifted by the cylinder's rotation. They then pass through a partition panel into the second silo for final grinding before being discharged.
Internal Components
- Ladder lining board
- Corrugated lining board
- Flat lining board
- Monolayer partition panel
