Concrete Truck Mixer with 12 Cubic Meter Drum
This concrete truck mixer is designed for efficient concrete transportation and mixing. Its high-capacity mixing drum ensures thorough mixing and consistent concrete quality.
Technical Specifications
Overview
High-Capacity Concrete Transport Solution
The CTM12 is a heavy-duty concrete truck mixer designed for large-scale construction projects and commercial mixing stations. Featuring a 12 cubic meter capacity and a robust 8x4 chassis, it ensures efficient delivery of high-quality concrete while maintaining optimal workability. The system is engineered with wear-resistant materials and world-class hydraulic components to provide reliable performance in demanding environments.
Performance Metrics
Key Performance Metrics
12 m³
Mixing Capacity
371 HP
Engine Power
31,000 kg
Rated Loading
18.4 m³
Geometric Volume
Mixing System
Mixing Drum Specifications
| Feature | Specification |
|---|---|
| Drum Material | Q345B Wear-resistant Steel |
| Max External Diameter | 2342 mm |
| Drum Length | 6322 mm |
| Inclination Angle | 12° |
| Mixing Speed | 0-14 r/min |
| Feeding Speed | ≥3 m³/min |
| Discharging Speed | >1 m³/min |
| Residual Rate | <0.2% |
Chassis & Engine
Chassis & Engine Details
- Driving Type: 8x4
- Engine Model: WD615.47 Diesel
- Displacement: 9726 ml
- Emission Standard: Euro 2
- Max Speed: 90 km/h
- Wheel Base: 1800+3200+1350 mm
- Curb Weight: 11000 kg
Technical Features
Advanced Features
- Double logarithmic variable pitch helical mixer blades for segregation-free mixing
- Hard-wearing alloy steel T-shape blades for extended service life
- Pneumatic water supply system with 450L tank capacity
- Shot-blasting steel surface treatment with airless paint coating
- High-performance hydraulic components (Pump, Motor, Reducer)
Standards & Compliance
- Certifications
- ISO 9001:2015CE CertifiedGB/T19001-2016
Operational Dimensions
- Overall Dimensions
- 10611 x 2500 x 3990 mm
