Concrete Mixer Semi-Trailer with 12m³ Drum
This concrete mixer semi-trailer is designed for efficient on-site concrete mixing and transportation. It features a 12m³ mixing drum, a robust chassis, and a reliable discharge system.
Technical Specifications
Overview
High-Capacity Concrete Mixer Semi-Trailer
This high-capacity concrete mixer semi-trailer is engineered for efficient transportation and on-site mixing of concrete. Featuring a robust 12m³ drum and a heavy-duty chassis with a 3-axle configuration, it ensures stability and consistent performance on demanding construction sites. The integrated hydraulic system and high-performance diesel engine provide reliable mixing power, while the durable steel construction guarantees long-term operational longevity.
General Specifications
- Overall Dimensions
- 9500 × 2500 × 3850 mm
- Mixing Drum Capacity
- 12 m³
- Number of Axles
- 3
Mixer Body & Performance
Operational Performance
3 m³/min
Min. Feeding Speed
3.5 m³/min
Min. Discharge Speed
16 rpm
Max. Rotation Speed
- Material Grade
- Q345
- End Plate Thickness
- 6 mm
- Mixer Body Thickness
- 6 mm
- Mixer Blade Thickness
- 5 mm
Power & Hydraulics
- Engine Power
- 140 hp
- Hydraulic System
- Hydraulic ReducerHydraulic PumpHydraulic Motor
Cleaning System
- Water Tank Capacity
- 350 L
- Water Supply Method
- Air pressure
Chassis
- Beam Type
- I-beam
- Axle Load Capacity
- 13 Ton
