Circular Vibrating Screen for Material Separation
This circular vibrating screen uses a cylindrical eccentric shaft exciter and eccentric block for amplitude adjustment. It is designed for quarrying materials and can also be used in mines, coal preparation, and mineral processing for product classification.
Technical Specifications
Overview
High-Efficiency Circular Vibrating Screen
This circular vibrating screen utilizes a cylindrical eccentric shaft exciter and eccentric blocks to generate powerful, adjustable circular motion for superior material stratification. Designed for demanding applications such as quarrying, mining, coal preparation, and mineral processing, it features a robust structure that ensures reliable operation under heavy-duty conditions. The machine balances high frequency with a large inclination angle to maximize processing capacity while maintaining energy efficiency and reduced operational noise.
Features
- Key Advantages
- High Screening EfficiencyLow Vibration NoiseStrong Excitation ForceConvenient MaintenanceDurable Construction
Operational Parameters
Main Technical Parameters
| Model | Layers | Screen Area (mm) | Capacity (t/h) | Motor Power (kW) |
|---|---|---|---|---|
| 2YA1548 | 2 | 1500x4800 | 22-150 | 15 |
| 2YA1860 | 2 | 1800x6000 | 65-586 | 22 |
| 2YA2160 | 2 | 2100x6000 | 81-720 | 30 |
| 2YA2460 | 2 | 2400x6000 | 90-810 | 37 |
| 2YK3072 | 2 | 3000x7200 | 180-1300 | 30x2 |
Performance Metrics
