Technical Specifications
Product Overview
Compact Residential Softening
The RL-R50A series provides an automatic and economical solution for residential water softening in space-constrained environments. These cabinet-style systems integrate both resin and brine tanks into a single streamlined unit, making them ideal for varied installation settings. Designed for households of 2-3 people, the system effectively reduces water hardness to protect plumbing and appliances from scale buildup.
- Suitable Applications
- Residential2-3 Person HouseholdsSpace-Saving
Performance Metrics
Key Operational Metrics
0.8 m3/h
Max Flow Rate
0.6 mmol/L
Output Hardness Limit
0.6 MPa
Max Feedwater Pressure
Technical Specifications
Model Specifications
| Parameter | RL-R50A1 | RL-R50A |
|---|---|---|
| Flow Range | 0.3~0.5 m3/h | 0.5~0.8 m3/h |
| Softened Water Cap. | 1.2 m3 | 1.6 m3 |
| Resin Volume | 4.5 L | 6 L |
| Tank Type | 0713 | 0717 |
Installation Parameters
- Feedwater pressure: 0.15~0.6 MPa
- Feedwater temperature: 5~38 °C
- Inlet/Outlet diameter: 3/4 inch
