Bulk Material Belt Conveyor
This belt conveyor efficiently transports bulk materials in industries such as mining, metallurgy, and construction. It is designed for continuous material handling, offering a robust construction for reliable operation.
Technical Specifications
Product Overview
Industrial Bulk Material Conveyor
This industrial belt conveyor system is engineered for high-efficiency bulk material handling across diverse sectors including mining, metallurgy, chemical, and power generation. It features a robust, adaptable design capable of handling various lumpy and powdery materials with high throughput. With flexible power options and multi-point drive capabilities, this system ensures reliable, continuous operation in demanding environments.
Operational Capacity
- Volume Capacity
- 3000 m³/h
- Belt Speed
- 5 m/s
- Storage Length
- 600 m
Technical Specifications
- Bandwidth Range
- 650 - 1400 mm
- Dip Angle
- -5° to +5°
- Driving Drum Diameter
- 500 - 1250 mm
- Roller Diameter
- 89 - 159 mm
Power & Drive
Power Configuration
400 KW
Single Drive Max Power
560 KW
Multi-Machine Max Power
- Drive Modes
- Multi-point driveFloating point supportFast adjustment fitting
Application Areas
Suitable Industries
CoalMetallurgyMiningPortsPowerBuilding MaterialsChemicalPetroleum
