Benchtop Wood Jointer with Open Stand
This benchtop jointer is a woodworking machine used to create flat surfaces along the length of a board. It features adjustable infeed and outfeed tables and is mounted on an open stand for stability.
Technical Specifications
Overview
Precision Woodworking Performance
This 6-inch benchtop jointer is designed to deliver professional-grade flatness and precision for woodworking projects. Featuring a robust 1,100W motor and a three-knife cutter block, it ensures efficient material removal and smooth surface finishes. With an adjustable fence and stable open stand, this machine provides the versatility and reliability needed for both small workshops and demanding tasks.
Technical Specifications
Cutter Block Speed
4,800 rpm
50Hz Speed
5,760 rpm
60Hz Speed
- Motor Power
- 1100 W
- Cutter Block Diameter
- 63.5 mm
- Number of Cutting Knives
- 3
Dimensions & Capacity
- Table Size
- 190 x 1,170 mm
- Maximum Planing Width
- 152 mm
- Maximum Cutting Depth
- 13 mm
- Rabbeting Capacity
- 13 x 152 mm
Fence & Dust Collection
- Fence Size
- 114 x 745 mm
- Fence Tilt Range
- 0 to 45 degrees
- Dust Chute Diameter
- 100 mm
Logistics
- Weight (Net/Gross)
- 95 / 110 kg
- Overall Dimensions
- 1,170 x 711 x 991 mm
- Packing Dimensions
- 1,220 x 520 x 410 mm
- Units per 20ft Container
- 85
Included Accessories
Included Accessories
- Push blocks (2)
