Benchtop Dispensing Machine for Dual Cartridge Adhesives
This benchtop dispensing machine is designed for the precise and efficient dispensing of adhesives from 50ml dual cartridges. It is suitable for applications requiring controlled and accurate dispensing of adhesives, sealants, and other fluids.
Technical Specifications
Overview
Precision Dispensing for Dual Cartridges
This benchtop dispensing machine is engineered for high-precision application of two-part adhesives, such as epoxy resin and AB glue, packaged in 50ml dual cartridges. Featuring a robust design with high-precision stepper motors and linear guides, it ensures consistent, repeatable dispensing for complex patterns including 3D lines, circles, and arcs. Designed for industrial efficiency, this system helps reduce material waste and improves overall product quality in assembly environments.
Key Features
- Certifications
- CE Approved
- Compatible Materials
- AB GlueEpoxy ResinTwo-part Glue
Technical Specifications
Working Area Options
| Model | Range (X/Y/Z) | Dimensions (WxDxH) | Weight |
|---|---|---|---|
| TH-2004D-300 | 300x300x100mm | 500x580x610mm | 37.5 |
| TH-2004D-400 | 400x400x100mm | 600x680x610mm | 42.5 |
| TH-2004D-500 | 500x500x100mm | 700x780x610mm | 49.5 |
Operating Conditions
- Temperature: 0 to 40°C
- Humidity: 20 to 90% (No condensation)
- Power Supply
- AC110V/220V (Internal conversion)
- I/O Signals
- 4 Inputs / 4 Outputs
Performance Metrics
System Performance
800 mm/s
X/Y Speed
350 mm/s
Z Speed
9,999 programs
Memory Capacity
