Automated Thread Coating Machine with Syringe Dispenser
This automated machine applies sealant to threads using a 30cc syringe dispensing system. It is suitable for coating screws, bolts, nuts, plugs, and various pneumatic connector fasteners.
Technical Specifications
Product Overview
Automated Thread Coating System
The TH-960L5 is a specialized automated system designed for the precise application of anaerobic thread sealants on screws, bolts, nuts, and pneumatic connectors. Featuring a dedicated 30cc syringe dispensing mechanism, it ensures consistent material delivery with a high production rate of 3-5 seconds per piece. This robust machine is optimized for industrial fasteners, supporting thread sizes from M5 to M30 with high-precision motor control.
Technical Specifications
Performance Metrics
3 sec
Minimum Cycle Time
5 sec
Maximum Cycle Time
10.5 kg
Total Weight
- Physical Dimensions
- 370 x 300 x 410 mm
- Thread Size Range
- M5-M30
- Input Voltage
- 110/220VAC (Internal Conversion)
Operational Capabilities
Certifications
CE Approved
- Supported Sealant Packing
- 50ml30ml10ml5ml3ml
Standard Kit Contents
Standard Dispensing Kit
- 30CC Syringe/barrel
- Barrel adapter
- Air tube
- S/S dispensing tips (5pcs)
- Foot pedal (2 core)
- 220V power cable
