Automated Steel Grating Welding Machine
This automated machine is designed for efficient and precise production of steel gratings. It features multiple welding heads and a conveyor system for continuous material processing.
Technical Specifications
Product Overview
Industrial Steel Grating Production
The ZH-800-2A-2 is an automated steel grating welding line engineered for high-volume manufacturing of industrial gratings. The system integrates a gantry-type welding mechanism with automated feeding systems for both flat and cross bars, ensuring consistent welding quality. With an adjustable production width of up to 1000mm and a working beat of under 12 seconds per two pieces, this equipment provides efficient output for large-scale construction projects.
Technical Specifications
Efficiency Metrics
12 seconds
Working Beat
- Electrical Input
- 3-phase, 380V, 50Hz
- Required Transformer
- 800 KVA
- Maximum Welding Pressure
- 75 T
Production Capabilities
Bar Spacing Options
| Component | Spacing (mm) |
|---|---|
| Flat Bars | 30, 40 |
| Cross Bars | 50, 100 |
- Finished Grating Size
- 1000 x 6000 mm (Adjustable)
Raw Material Compatibility
Flat Bar Dimensions
- Width: 25-60mm
- Thickness: 2-5mm
- Length: Up to 6000mm
- Compatible Materials
- Hot-roll steelCold-roll steel
Control & Automation
Operating Modes
ManualAutomatic
System Capabilities
- Automatic cross bar feeding
- Automatic flat bar feeding
- Automatic welding distortion correction
- Intelligent digital parameter display
