Automated Bearing Production Line with CNC Diameter Axial Ring Rolling
This automated production line is designed for bearing manufacturing. It features a four-working station CNC diameter axial ring rolling machine for precise and efficient production.
Technical Specifications
Product Overview
Automated Bearing Production Line
This automated production line utilizes advanced computer numerical control (CNC) technology to integrate mechanical, electrical, and hydraulic systems into a seamless manufacturing solution. Designed for the high-quality processing of seamless rings, the equipment offers superior process characteristics for efficient, high-volume production. By minimizing human intervention, the system enhances manufacturing consistency and reduces overall production costs.
Technical Specifications
Ring Dimensions
180 mm
Min Outer Diameter
300 mm
Max Outer Diameter
35 mm
Min Height
100 mm
Max Height
Rolling Force
300 KN
Max Radial Force
300 KN
Max Axial Force
Operational Parameters
| Parameter | Value |
|---|---|
| Rolling line speed | ~1.3 m/s |
| Stroke of the Core-roller | 150 mm |
| Cone-roller range | 30-150 mm |
| Diameter of roller core | 60 mm |
| Max ring weight | 10 Kg |
System Components
- Integrated Systems
- Mechanical IntegrationElectrical IntegrationHydraulic IntegrationInstrument IntegrationLubricating SystemCooling System
