Aluminum Housing Single-Phase Electric Motor
This single-phase electric motor features an aluminum housing. It is designed for applications requiring single-phase power and comes in frame sizes from 56 to 112, with outputs ranging from 0.06 KW to 4 KW.
Technical Specifications
Product Overview
High-Performance Single-Phase Aluminum Motors
These aluminum housing single-phase asynchronous motors are engineered for reliability and efficient operation in various industrial and small machinery applications. Available in both ML (dual-capacitor) and MY/MYT (capacitor-run) series, they offer versatile power output ranges and frame sizes to suit diverse requirements. Designed to conform to IEC standards, these motors provide a balance of high starting torque, low noise, and lightweight construction.
Technical Specifications
ML Series Performance
| Metric | Specification |
|---|---|
| Power Range | 0.18KW - 4KW |
| Frame Size | 63 - 112 |
| Starting Torque | Up to 2.5x rated |
| Design | Dual-capacitor asynchronous |
MY/MYT Series Performance
| Metric | Specification |
|---|---|
| Power Range | 0.09KW - 3KW |
| Frame Size | 56 - 100 |
| Starting Torque (MY) | 0.3 - 0.7x rated |
| Starting Torque (MYT) | 0.45 - 0.75x rated |
| Design | Capacitor-run asynchronous |
Efficiency Indicators
0.88
Power Factor (Cos φ)
55
Protection Class (IP)
Key Features
- Product Highlights
- Aluminum HousingIEC Standard CompliantLow NoiseLow VibrationLightweightEasy Maintenance
Typical Applications
Common Use Cases
- Air Compressors
- Pumps
- Small Industrial Machinery
- General Purpose Industrial Equipment
