Technical Specifications
Overview
Industrial Air Separation Capability
This advanced air separation plant is engineered for the simultaneous production of high-purity oxygen, nitrogen, and argon. Designed for continuous industrial operation, the system utilizes cryogenic distillation to effectively separate atmospheric air into its primary components. These units are suitable for large-scale facilities requiring a reliable, high-volume supply of industrial gases.
Operational Metrics
- Operation Period
- 24 months
Performance Data
Model Production Specifications
| Model | Oxygen Output (Nm³/h) | Nitrogen Output (Nm³/h) | Argon Output (Nm³/h) |
|---|---|---|---|
| KDON-1500/1500/30 | 1,500 | 1,500 | 30 |
| KDON-3200/3200/80 | 3,200 | 3,200 | 80 |
| KDON-4500/4500/120 | 4,500 | 4,500 | 120 |
| KDON-6000/6000/180 | 6,000 | 6,000 | 180 |
| KDON-10000/10000/350 | 10,000 | 10,000 | 350 |
| KDON-15000/15000/550 | 15,000 | 15,000 | 550 |
| KDON-20000/20000/700 | 20,000 | 20,000 | 700 |
| KDON-25000/25000/820 | 30,000 | 30,000 | 820 |
| KDON-30000/30000/1000 | 35,000 | 35,000 | 1,000 |
| KDON-48000/48000/1700 | 48,000 | 48,000 | 1,700 |
Purity Standards
Output Purity Levels
99.6 %
Oxygen Purity
10 ppmO2
Nitrogen Purity (Max)
2 ppm
Argon Purity (O2 Content)
3 ppm
Argon Purity (N2 Content)
System Features
- Gases Produced
- OxygenNitrogenArgon
