Technical Specifications
Product Overview
High-Performance Agricultural Disc Blades
These professional-grade disc blades are engineered for superior soil tillage and seedbed preparation across various agricultural applications. Manufactured using world-advanced technology, they offer exceptional resistance to breakage and long wear life in demanding field conditions. Available in both plain and notched styles, these blades are designed to fit a wide range of harrows, plows, and cultivators.
Material & Durability
Hardness Specifications
- 65Mn Steel: HRC 40-44
- Boron Steel: HRC 48-52
Performance Features
Wear ResistantBreakage ResistantHeat TreatedHot Forged
- Available Materials
- 65Mn SteelBoron Steel
Technical Specifications
Standard Dimensions
| Diameter (mm/inch) | Thickness (mm) | Plain Weight (kg) | Notched Weight (kg) |
|---|---|---|---|
| 300mm (12") | 3 | 1.6 | 1.1 |
| 330mm (13") | 3 | 1.8 | 1.2 |
| 360mm (14") | 3 | 2.3 | 1.5 |
Available Styles
- Plain Disc
- Notched / Scalloped Disc
Manufacturing & Quality
Manufacturing Standards
- Advanced heat treatment process
- Rigorous dimensional checks
- Hardness testing protocols
- Custom production based on drawings or samples
Experience
15 Years
Years Exporting
3
Production Lines
