Adult Pull-Up Diaper Production Machine
This machine is engineered for the high-volume production of adult pull-up diapers. It integrates material feeding, core forming, SAP application, non-woven wrapping, cutting, folding, and sealing processes.
Technical Specifications
Product Overview
High-Efficiency Adult Pull-Up Diaper Production
This fully servo-driven adult pull-up diaper machine is engineered for high-volume, continuous manufacturing of incontinence products. It integrates advanced processes including core formation, SAP application, elastic attachment, and precise folding to ensure consistent, high-quality output. Designed for reliability, the system features a robust PLC control architecture that maximizes efficiency while minimizing downtime during operation.
Technical Performance
- Design Speed
- 300 pieces/min
- Working Speed (M size)
- 250 pieces/min
- Wiring Configuration
- 3*70mm2 + 1*25mm2 + 1*16mm2
Quality & Efficiency
- Qualified Rate
- ≥ 97%
- Efficiency
- 85 %
Infrastructure Requirements
- Total Power Consumption
- 450KW (main) / ~600KW (incl. glue system)
- Power Supply
- 380V ±5%, 50HZ
- Compressed Air
- ≥0.8Mpa, 3m³/min
Physical Specifications
- Total Weight
- 105 tons
