Technical Specifications
Overview
Robust Agricultural Performance
This versatile wheeled tractor series is engineered for high reliability and strong power in demanding field conditions. Featuring a 16F+8R transmission, it provides excellent speed matching and agronomic adaptability for tasks like plowing, tilling, and heavy lifting. Designed with operator comfort in mind, it includes an ergonomic cabin, side-mounted controls, and optional air-conditioning to ensure productivity during long shifts.
Performance Metrics
Power Output
66.2 kW
Calibration Power (RC904/954)
81 kW
Calibration Power (RC1104)
2,400 r/min
Calibration Speed
Technical Specifications
Drive & Dimensions
| Feature | Specification |
|---|---|
| Drive Type | 4x4 Wheel Drive |
| Dimensions (L x W x H) | 4382 x 2083 x 2935 mm |
| Wheelbase | 2193.5 mm |
| Min. Clearance | 415 mm |
| Weight | 3550 - 3800 kg |
Transmission System
- 16 Forward + 8 Reverse gears
- Double-acting clutch
- Gear sleeve shift
- Side-mounted operating mechanism
Operational Features
Operator Station
Side-set controlErgonomic designOptional air-conditioningHigh visibility
- Hydraulic & Braking
- Double oil cylinder pressure liftingFull hydraulic steeringOil bath disc brakesType 2 post-three-point suspension
