80mm 0.75kW 220V AC Servo Motor
This 80mm servo motor provides 0.75kW of power and operates at 220V. It is designed for precise motion control in applications such as robotics and CNC machinery.
Technical Specifications
Product Overview
High-Performance 80mm Servo Motor
This 0.75kW AC servo motor is engineered for precision motion control in demanding industrial environments. Featuring a compact 80mm frame size, it provides a balance of high torque density and reliability. It is an ideal solution for applications requiring accuracy, such as robotics, CNC machinery, and advanced electronic manufacturing equipment.
Key Performance Metrics
Operational Metrics
0.75 kW
Rated Power
2.39 Nm
Rated Torque
3,000 rpm
Rated Speed
7.2 Nm
Max. Torque
Technical Specifications
Core Specifications
| Parameter | Value |
|---|---|
| Rated Voltage | 220V AC |
| Frame Size | 80mm |
| Rated Current | 4.8A |
| Max. Current | 13.4A |
| Max. Speed | 6000 rpm |
Applications & Features
Design Advantages
- Compact Structure
- Short Body Design
- High Precision Encoding
- Reliable Industrial Construction
- Target Applications
- Jointed RobotsPicking RobotsCNC MillingEngravingElectronic Equipment
