6000HP Electric Fracturing Pump
This 6000HP electric fracturing pump integrates mechatronics, a medium voltage AC VF drive, and direct drive transmission. The pump unit's layout meets the high load and continuous working condition requirements for unconventional oil and gas resource development.
Technical Specifications
Product Overview
High-Efficiency Electric Fracturing Solution
The 6000HP Electric Fracturing Pump is engineered for large-scale hydraulic fracturing operations, offering a high-performance, mechatronics-integrated solution for unconventional oil and gas resources. By utilizing a direct-drive motor system, this unit eliminates the need for complex diesel engine and gearbox maintenance while providing superior power and displacement. Its advanced AC VF control system ensures precise, automatic regulation of flow and pressure, significantly reducing operational costs, energy consumption, and labor requirements compared to conventional equipment.
Key Performance Metrics
Performance Highlights
Technical Specifications
Detailed Specifications
| Parameter | Value |
|---|---|
| Cylinder Number | 5 |
| Stroke Length | 304.8 mm |
| Max Stroke Number | 230 SPM |
| Max Connecting Rod Force | 1,030 kN |
| Gear Ratio | 5.6087:1 |
| Motor Voltage | 6,000 V |
| Motor Current | 508 A |
| Motor Protection Grade | IP43 |
Operational Features
Key Operational Advantages
- Zero emissions and low noise for night operation
- Double overpressure protection system (electronic + mechanical)
- Stepless regulation of flow and pressure
- Constant pump pressure and constant displacement modes
- 50% reduction in energy consumption costs
- 40% reduction in consumable parts costs
Physical Dimensions
- Dimensions & Weight
- Unit Size: 5,800 x 2,600 x 3,112 mm | Weight: 36,838 kg
