5kW Home Energy Storage System
This household energy storage system is designed to couple with photovoltaic generation using a long-life lithium iron phosphate battery. Electricity generated by solar cells can be utilized offline, and redundant generation can be sold to the power grid.
Technical Specifications
Overview
High-Capacity Home Energy Storage
This household energy storage system is designed to integrate seamlessly with photovoltaic generation, utilizing a long-lifetime, environmentally friendly lithium iron phosphate (LFP) battery. With an output power of 5kW, it offers a flexible management system that supports both off-grid operation and on-grid energy selling. It is an ideal solution for homes with PV panels, small business buildings, and office areas looking to optimize electricity usage during peak and valley price periods.
- Model Number
- RE5000
- Installation Method
- Floor Type
Power & Performance
Key Performance Metrics
- AC Output Specifications
- 230VAC ±2%, 50Hz/60Hz
- AC Maximum Output Current
- 22.1 A
Battery Specifications
- Battery Type
- Lithium Iron Phosphate (LFP)
- Rated Voltage
- 51.2 V
- Battery Capacity
- 100 Ah
PV & Grid Integration
- PV Input Voltage Range
- 125V - 550V
- PV Maximum Input Voltage
- 580 V
- Grid Connection
- Single-Phase
- Grid Voltage Range
- 180V - 270V
Compliance & Environment
Safety Certifications
- Operating Temperature
- -10°C to 55°C
