5.12kWh Lithium Ion Battery System
This 5.12kWh lithium ion battery system provides efficient energy storage. It is designed for residential and commercial applications, providing backup power and maximizing the use of renewable energy.
Technical Specifications
Overview
High-Performance Energy Storage
This 5.12kWh lithium-ion battery system provides a reliable, scalable energy storage solution for residential and commercial solar applications. Designed for maximum efficiency, it offers a 90% depth of discharge and a roundtrip efficiency of over 99%, ensuring your solar power is used effectively. Its compact, plug-and-play design and long service life make it a versatile choice for achieving energy independence.
Performance
- Rated Capacity
- 5.12 kWh
- Roundtrip Efficiency
- >99%
- Depth of Discharge
- 90 %
- Cycle Life
- 6000 cycles (capacity >80%)
Electrical
Charge/Discharge Current
100 A
Recommended
150 A
Maximum
- Rated Voltage
- 51.2 V
- Voltage Range
- 44.5 - 58.2V
Physical
- Dimensions (W x H x D)
- 342mm x 600mm x 207mm
- Weight
- 52 kg
Compliance
- Safety Standards
- CERCMTUV (IEC62619)UL1973ROHS
