40A Earth Leakage Circuit Breaker with NT50 Panasonic Design
This earth leakage circuit breaker offers reliable protection against ground faults. The device features a 40A current rating and NT50 design.
Technical Specifications
Product Overview
Compact Earth Leakage Protection
The TRL-40(b) is a high-performance mini safety breaker engineered for effective earth leakage and ground fault protection. Featuring a compact NT50-inspired design, it allows for easy assembly and efficient space utilization in electrical distribution systems. This reliable device is designed to meet international safety standards, making it an essential component for safeguarding circuits in diverse applications.
Key Features
- Advantages
- Compact SizeEasy AssemblyPatent DesignGround Fault Protection
Performance Metrics
Performance Ratings
40 A
Max Rated Current
2.5 KA
Short Circuit Capacity
0.1 s
Residual Off-time
Technical Specifications
Core Electrical Data
| Parameter | Value |
|---|---|
| Poles | 2 |
| Rated Voltage | 110V / 220V AC |
| Rated Current | 16A, 20A, 25A, 32A, 40A |
| Operating Current (IΔn) | 15mA, 30mA |
| Type of Operation | AC |
Dimensions & Build
- Dimensions: 70mm x 32mm x 51mm
- Electrical Endurance: 1000 operations
- Mechanical Endurance: 2000 operations
- Material: Plastic and Bakelite
Compliance & Certification
Standards & Approvals
IEC/EN 61008-1GB 16916.1CECCC
