Technical Specifications
Overview
High-Performance Mining Motor Grader
This 250HP motor grader is engineered for heavy-duty earthmoving, ground leveling, and road construction in demanding environments such as mining sites, airports, and highways. It utilizes advanced load-sensitive hydraulics and energy-efficient power control technology to provide operators with precise, micro-level control. The machine features a rugged design, including a wet-type brake axle and an elevated, vibration-dampened cabin for superior reliability and operator comfort.
Engine & Performance
Rated Power
178 kW
Rated Power
2,200 rpm
Rated Speed
- Engine Model
- QSB6.7
Technical Dimensions
- Overall Dimensions
- 9300 x 2625 x 3420 mm
- Total Weight
- 17000 kg
- Front to Rear Axle Distance
- 6447 mm
- Front Axle Ground Clearance
- 586 mm
Components
- Tire Specification
- 17.5-25
Key Advantages
Performance Highlights
- Load-sensitive hydraulic system for precise micro-control
- Intelligent fan control for energy efficiency and noise reduction
- Wet-type brake axle for high reliability
- Advanced vibration and noise reduction technology
- Torque converter interlock for high transmission efficiency
