240 t/h Asphalt Mixing Plant
This asphalt mixing plant produces up to 240 tons of asphalt per hour. It integrates aggregate supply, drying, screening, weighing, and mixing systems with a pulse-controlled dust collector.
Technical Specifications
Overview
Industrial-Grade Performance
The QLB3000 is a high-capacity stationary asphalt mixing plant engineered for professional road construction and infrastructure projects. It features an advanced modular design that integrates precision aggregate feeding, high-efficiency drying, and world-class mixing technology. Equipped with automated control systems and a sophisticated dual-stage dust collection method, this plant ensures consistent quality while maintaining compliance with modern environmental standards.
Performance Metrics
Production Specifications
240 t/h
Production Capacity
626 kW
Main Power Requirement
2,000 kg
Mixer Capacity
Technical Details
Core Technical Specifications
| Feature | Specification |
|---|---|
| Dedust Method | Two-stage: Cyclone + Bag Collector |
| Asphalt Tank Capacity | 25 - 200 t |
| Burner Fuels | Coal, Diesel, Heavy Oil, Gas |
Static Measuring Accuracy
- Aggregate: ±0.5%
- Asphalt: ±0.25%
- Powder: ±0.25%
Key Features
Technology Highlights
Twin Horizontal Mix ShaftAuto-Lubrication SystemBoiler Steel Drying DrumThermal InsulationModular Design
