200cc Oil-Cooled All-Terrain Vehicle with CVT Transmission
This ATV features a CVT automatic transmission and a 200cc oil-cooled engine. It is compliant with EEC EURO4 emissions standards.
Technical Specifications
Overview
ATV X Super 200 Overview
The ATV X Super 200 is a versatile, utility-focused all-terrain vehicle designed for both recreational and professional use. Engineered with a reliable 200cc oil-cooled engine and a responsive CVT automatic transmission, it offers ease of operation across various terrains. This model is fully compliant with EEC EURO4 and 168/2013 standards, making it a robust choice for markets requiring strict emission and safety certifications.
Engine & Performance
Engine Specifications
200 cc
Engine Displacement
10.5 kW
Max Power
10.7 Nm
Max Torque
55 km/h
Max Speed
Technical Details
| Specification | Value |
|---|---|
| Cooling System | Oil cooling |
| Bore x Stroke | 62.5 x 57.8 mm |
| Compression Ratio | 10.0:1 |
| Ignition | CDI |
| Transmission | CVT Automatic |
Dimensions & Build
Physical Dimensions
1,750 mm
Length
1,110 mm
Width
1,120 mm
Height
214 kg
Net Weight
- Wheelbase
- 1110 mm
Electrical & Fuel
- Fuel Tank Capacity
- 6.7 L
- Battery
- 12V 9Ah
- Start Method
- Electric
Compliance & Logistics
Certifications
EEC EURO4EEC 168/2013
- Available Colors
- RedBlackWhiteBlue
- Shipping Quantity
- 54pcs per 40HQ
