12V 100Ah GEL Battery
This 12V 100Ah GEL battery is designed for high reliability and superior performance. Its robust construction and GEL electrolyte ensure maintenance-free operation and enhanced safety, making it ideal for various applications requiring deep cycling and long service life.
Technical Specifications
Overview
High-Performance Deep Cycle GEL Battery
The PGF100-12 is a professional-grade 12V 100Ah deep cycle GEL battery engineered for reliability and long service life. Featuring maintenance-free, spill-proof construction and advanced GEL technology, it provides consistent power for demanding applications like solar systems, UPS, and telecommunications. With a design life of up to 12 years and robust safety features, this battery is an ideal solution for uninterrupted power requirements.
Electrical Specifications
Rated Capacity
100 Ah
C10 Rate
110 Ah
C20 Rate
Charging Parameters
| Usage Type | Voltage Range |
|---|---|
| Cycle Use | 14.4-15.0V (25°C) |
| Standby Use | 13.5-13.8V (25°C) |
- Rated Voltage
- 12 V
Physical & Mechanical
- Dimensions (L*W*TH)
- 507 x 110 x 231 mm
- Gross Weight
- 28.5 kg
- Container Material
- ABS
Performance & Durability
- Design Life
- 12 years (floating use)
- Cycle Life
- 1200 times at 30% DOD
Features & Compliance
Maintenance Type
Maintenance FreeSealed Type
Recommended Applications
- UPS Equipment
- EPS Power
- Energy Storage Systems
- Solar Systems
- Wind Power Systems
- Inverter Systems
- Telecom Systems
- Certifications
- ISO9001ISO14001OHSAS18001CEUL
