100 HP 4WD Farm Tractor
This 100 HP 4WD tractor is equipped with a YTO/YUCHAI engine and a LUK 12in double-acting clutch. It also features a 150L fuel tank for extended operation.
Technical Specifications
Overview
High-Efficiency 100 HP Agricultural Tractor
The QLN1004 is a robust 4WD agricultural tractor engineered for versatile farming operations including plowing, tilling, and hauling. Equipped with a reliable water-cooled 4-cylinder diesel engine, it offers excellent fuel economy and high economic efficiency for professional agricultural use. With a spacious cabin and ergonomic controls, it ensures operator comfort during extended work hours in demanding field conditions.
Engine Performance
Rated Power
73.5 kW
Rated Power
2,200 r/min
Rated Speed
Engine Technical Details
- Direct-injection 4-cylinder diesel engine
- Water-cooled cooling system
Dimensions and Weight
Dimensions & Mass
| Metric | Value |
|---|---|
| Dimensions (L x W x H) | 4280 x 2085 x 2925 mm |
| Dry Mass (with cabin) | 3915 kg |
| Min. Ground Clearance | 450 mm |
Technical Specifications
- Drivetrain Configuration
- 4WDDouble-acting clutchDry Dual Stage
- Fuel Tank Capacity
- 150 L
- PTO Speed
- 540/1000 rpm
- Wheel Tread F/R
- 1520/1620 mm
