Vibratory Feeder
The vibratory feeder uniformly and continuously feeds bulk and granular materials to receiving devices. It is used in crushing and sieving combined equipment across industries like metallurgy, mining, and building materials.
Technical Specifications
Overview
High-Efficiency Vibratory Feeder
This industrial vibrating feeder is designed for uniform, continuous material handling in demanding environments such as mining, metallurgy, and construction. By utilizing a high-performance eccentric block vibrator, it ensures consistent flow to crushers and processing equipment while minimizing noise and energy consumption. The robust construction is engineered for long service life, easy maintenance, and reliable operation even under heavy-duty conditions.
- Key Advantages
- Stable VibrationAdjustable Feed RateLow NoiseEnergy EfficientEasy Maintenance
Technical Specifications
Model Specifications
| Model | Funnel Size (mm) | Capacity (t/h) | Power (kW) |
|---|---|---|---|
| GZD-600×1800 | 600×1800 | 30-80 | 1.1×2 |
| GZD-800×3000 | 800×3000 | 80-120 | 1.5×2 |
| GZD-960×3800 | 960×3800 | 120-120 | 2.2×2 |
| GZD-1100×4200 | 1100×4200 | 200-430 | 3.7×2 |
| GZD-1300×5200 | 1300×5200 | 450-600 | 7.5×2 |
| ZSW-960×3800 | 960×3800 | 90-200 | 11 |
| ZSW-1300×4900 | 1300×4900 | 250-450 | 22 |
