Vertical Ring Rolling Machine - D51X Oblique Type
The vertical ring rolling machine, also known as a broaching machine, is available in the D51X oblique type. It is widely used in processing bearings, flanges, and seamless ring parts from various metal materials.
Technical Specifications
Product Overview
Precision Vertical Ring Rolling
The D51X oblique type vertical ring rolling machine is a specialized industrial solution designed for the efficient production of seamless ring parts. By utilizing an advanced oblique rolling process, it delivers high dimensional accuracy and consistent quality across various metal materials including steel alloys, copper, and aluminum. This versatile machine is highly favored by small and medium-sized enterprises for its ability to integrate seamlessly into existing forging workflows, effectively replacing traditional mandrel support methods to improve overall production efficiency.
Technical Capabilities
Compatible Materials
- High temperature alloy steel
- Bearing steel
- Plain carbon steel
- Copper
- Aluminum alloy
Industry Applications
- Suitable Processes
- UpsettingPunchingReamingRadial-Axial Rolling
Machine Specifications
Capacity Matrix
| D51 Model | 160 | 250 | 350 | 400 | 500 | 630 | 800 | 1000 |
|---|---|---|---|---|---|---|---|---|
| Outer Diameter (mm) | 200 | 250 | 350 | 400 | 500 | 630 | 800 | 1000 |
