Swimming Pool Heat Pump Water Heater
This swimming pool heat pump uses heat pump technology to get heat energy from the air and efficiently heat the water. The water and electricity are completely separated, with no open flame and no harmful gas produced, making it safe and environment-friendly.
Technical Specifications
Overview
Professional Swimming Pool Heat Pump
This advanced swimming pool heat pump utilizes efficient heat exchange technology to extract warmth from the air, providing a cost-effective and safe solution for pool temperature control. Featuring durable titanium alloy heat exchangers, it is designed to resist corrosion from chlorinated water while ensuring no open fire or harmful gas emissions. The system offers significant energy savings, reducing operating expenses by 65% to 80% compared to traditional heating methods.
Technical Specifications
Performance Matrix
| Model | HP | Heating Capacity (kW) | Rated Input Power (kW) |
|---|---|---|---|
| KFCRS-12II | 3 | 12 | 2.4 |
| KFCRS-19II | 5 | 19 | 3.7 |
| KFCRS-35II | 10 | 35 | 6.9 |
| KFCRS-45II | 12 | 45 | 8.9 |
- Refrigerant
- R410A
- Power Supply
- 380V~440V 50Hz
Compatibility
Recommended Pool Volumes
- 12kW: 27.43 m³
- 19kW: 43.42 m³
- 35kW: 79.85 m³
- 45kW: 102.82 m³
Features
- Main Advantages
- Titanium Alloy ExchangerCorrosion ResistantEco-FriendlyEnergy SavingIndoor/Outdoor Suitable
